TGas-1013 On-line Infrared SF6 Gas Transmitter
Fixed SF6 leakage Detector with Zigbee
Sent Email : sales@globeinstrument.com
TGas-1013 on-line infrared SF6 gas transmitter is base on the internet with SF6 gas quality monitoring instruments .It used online monitoring for toxic gases, SF6 gas, O2, temperature, humidity, etc. Fast response, high accuracy, with a variety of selectable signal output mode.Passed through the third grade EMC industry test. Compliance with IEEE 802.15.4 wireless communication standard, ZigBee communication protocol support
It is widely used in such electric power, Laboratory Etc. Not easy wiring of the occasion with stable and reliable performance.
- Compact structure, elegant appearance, easy installation
- RS485 bus. ZigBee wireless .Relay switch signal, 4 ~ 20mA four kinds of output mode output.
- Applies to toxic gases and sulfur hexafluoride (SF6) gas, oxygen (O2), temperature and humidity measurements, Detail see selection table.
- Passed through the third grade EMC industry test.
- Relay switching can be directly connected to the sound and light alarm device, used as a stand-alone alarm unit.
- In terms of electromagnetic compatibility and protection to meet the following requirements:
GB / T 17626.2-2006 3 level electrostatic discharge
GB / T 17626.4-2008 Level 3 EFT
GB / T 17626.5-2008 level 3 lightning (surge)
| Parameters | Characteristics |
| Detectable gas | Sulfur hexafluoride, oxygen, poisonous and harmful gases |
| Communication Interface | RS485 bus.ZigBee wireless .Relay switch signal,4 ~ 20mA four kinds of output mode output |
| Insulation Resistance | ≥1000MΩ |
| Measurement range | Refer to lectotype table for details |
| Sampling method | Diffusion |
| Working environment | Temperature: -30℃ ~ 60℃Pressure: 950～1050hPa Humidity: 10 ~ 90% RH (non-condensing) |
| Input voltage | 24VDC 12VDC~24VDC |
| Rated Power | 3W |
| Display | 6 * 2 LCD |
| Dimensions | 142 mm X100 mm X58mm |
| Weight | 350g |
| Model | Range | Accuracy | |
| SF6 | NDIR | 0-1500ppm | ±2%F.S. |
| O2 | Fluorescence quenching | 0~25% | ±2%F.S. |
| CO–1 | Electrochemical | 0-500ppm | ±5%F.S. |
| CO–2 | Electrochemical | 0-1000ppm | ±5%F.S. |
| H2S | Electrochemical | 0-100ppm | ±5%F.S. |
| SO2 | Electrochemical | 0-20ppm | ±5%F.S. |
| H2–1 | Electrochemical | 0~4%LEL | ±2%F.S. |
| H2–2 | Electrochemical | 0-1000ppm | ±5%F.S. |
